3.5 ADC + DAC PARAMETERS
Main-Unit is equipped with 8 D/A-Converters (CYAN) and 8 A/D-Converters (YELLOW).
RX
Variable
ATTENUATOR
0 ... 40 dB
Variable
RX GAIN 1
Variable
RX GAIN 2
A/D
GRAY-Ship
DSP
DAC
Rx-Gain 1
BW 5 MHz
950 - 1450
DAC
Rx-Gain 2
DAC
Rx-Attenuator
ADC
Rx-RF Level
TX
Variable
TX GAIN
ADC
LNB Current
950 - 1450
ADC
LNB Voltage
DAC
Tx-Gain
ADC
Tx-RF Level
ADC
BUC Current
ADC
BUC Voltage
BW 20 MHz
BW 3 Mhz
TX Gain
ADC
Rx-IF Level
D/A
GRAY-Ship
DSP
DAC
TCXO High
DAC
TCXO Low
x 16
ADC
TCXO Voltage
DAC
OCXO High
DAC
OCXO Low
x 16
OCXO TCXO
? MHz ? MHz
? MHz
