TSAT 3000 Configuration Parameter Description, January 2013 Page 111 of 124
3.15.6 UTL_DEBUG_MASK
Ver <= 30.4.1: Default 0x102D, Range 0…0xFFFF.FFFF
Ver >= 30.5.0: Default 0x170F, Range 0…0xFFFF.FFFF
Bit field to control the output of debugging messages.
Bit Mask Mnemonic Description
0
0x0001
DEBUG_CCU_MSG
Enable MSGs. Global enable/disable of all other
debug options (except bit 2 -
ENABLE_WARNING).
1
0x0002
DEBUG_BOARD_MESSAGES
MSG from BCTRL – Not Used.
2
0x0004
DEBUG_ENABLE_WARNING
Enable WARNINGs.
3
0x0008
DEBUG_DSP_MESSAGE
Ver >= 31.6.0: MSG from DSP
4
0x0010
DEBUG_PPR
Ver >= 30.3.0: MSG from PPR functions.
See also
PHL_SLOT_PHASE_MODE.
5
0x0020
DEBUG_SHOW_CRC_ERRORS
MSG when receive CRC error packets.
6
0x0040
DEBUG_DSP_SPECTRUM
MSG when receive Spectrum (and more) from DSP.
7
0x0080
DEBUG_PROC_SPECTRUM
MSG when processing Spectrum, and also send
processed Spectrum-packets to Service Ports.
8
0x0100
DEBUG_ABS_FREQ_CONTROL
MSG when Frequency is controlled.
9
0x0200
DEBUG_SLOTPHASE_SETPOINT
MSG when Slot Phase Setpoint or
Target-UW-Position is changed.
10
0x0400
DEBUG_ROUND_TRIP_DELAY
MSG when Round-Trip delay is changed.
11
0x0800
DEBUG_GAIN
MSG from Gain-Control.
12
0x1000
DEBUG_LINK_RESET_ACK
MSG when LINK_RESET / LINK_ACK are sent or
received (i.e. Open / Close Link).
13
0x2000
DEBUG_SECURE_LINK
MSG from Secure-Link (timeout, retransmitting,
discarding packets, etc.).
RT address filter:
UTL_DEBUG_RT_ADDRESS.
14
0x4000
DEBUG_SECURE_LINK_
ALSO_OK_PKTS
MSG of all Secure-Link packets.
RT address filter:
UTL_DEBUG_RT_ADDRESS.
15
0x8000
DEBUG_SWUL
Ver >= 30.2.0:
Enable MSG from Software Upload module.
