3.11 PHYSICAL LAYER PARAMETERS
3.11.1 PHL_{OUTBOUND | INBOUND}_SYMBOLRATE
Default 64000, Range 300…512000
Set Symbol-Rate for Outbound PHL_TX_HUB_FREQUENCY carrier.
Set Symbol-Rate for Inbound
PHL_TX_RT_FREQUENCY carrier.
Note: DSP will be restarted 10 seconds after you’ve changed CURRENT value.
Ver >= 30.8.0: Restart of DSP is enabled by bit 2 (0x0004) in
UTL_UTILITY_MASK.
3.11.2 PHL_{OUTBOUND | INBOUND}_MODULATION
Default 1, Range 1…3
Set Modulation for Outbound PHL_TX_HUB_FREQUENCY carrier.
Set Modulation for Inbound
PHL_TX_RT_FREQUENCY carrier.
Value Description
1 OQPSK
2 QPSK
3 24BPSK
Note: DSP will be restarted 10 seconds after you’ve changed CURRENT value.
Ver >= 30.8.0: Restart of DSP is enabled by bit 2 (0x0004) in
UTL_UTILITY_MASK.
