Debugging
A) Messages:
Some debug information is issued when you enable bit 22 or 23 (0xC0.000) in
UTL_DEBUG_MASK_B.
• Bit 22 – 0x40.000 –
DEBUG_TX_FREQUENCY_ADJUST_RX_2150 – Receiving packet from RT.
• Bit 23 – 0x80.000 –
DEBUG_TX_FREQUENCY_ADJUST_TX_2150 – Sending freq. adjust to RT.
Use
UTL_DEBUG_RT_ADDRESS to select appropriate RT.
B) RX Frequency:
Setting
UTL_MIRROR_CHANNEL = 102, will make the average RX frequency received from
RT defined by
UTL_DEBUG_RT_ADDRESS to appear in NMS – ‘Eb/No and Freq. Deviation’
window. The Reference-RT will be selected when
UTL_DEBUG_RT_ADDRESS is zero.
C) Reference-RT:
The HUB will always issue a message when Reference-RT is changed.
You may get/set the current Reference-RT by Text Command “test refrt”. Examples:
• “test ref” - Display current Frequency-Reference-RT.
• “test ref <rt>” - Change current Frequency-Reference-RT.
• “test ref <rt> p” - Change current Frequency-Reference-RT, and keep this settings
forever.
3.11.25 PHL_TX_FREQUENCY_ADJUST_BKUP
Default 0, Range –10000…+10000 – No-Current
Ver <= 30.8.0
Not Implemented.
Ver >= 31.0.0
HUB: Not Used.
RT: The parameter has the same interpretation as
PHL_TX_FREQUENCY_ADJUST.
This value is used when the Backup set of frequencies are used.
