3.15.7 UTL_DEBUG_MASK_B
Default 0x0000, Range 0…0xFFFF.FFFF
Bit field to control the output of debugging messages.
Ver <= 30.3.1:
Not Implemented.
Ver >= 30.4.0:
Bit Mask Mnemonic Description
0
0x0001
DEBUG_NETWORK_RX
Ver >= 30.7.0: MSG IP packets rx’ed from IP-Stack.
1
0x0002
DEBUG_NETWORK_TX
Ver >= 30.7.0: MSG IP packets sent to IP-Stack.
2
0x0004
DEBUG_INBOUND_
LINK_HEAD
Ver >= 30.8.0: MSG Link-Header of TSAT 2150
Inbound Network and Application packets.
3
0x0008
DEBUG_OUTBOUND_
LINK_HEAD
Ver >= 30.8.0: MSG Link-Header of TSAT 2150
Outbound Network and Application packets.
4
0x0010
DEBUG_H2H_CTRL
HUB Ver >= 30.4.0: MSG from HUB-2-HUB module
when connection to another HUB is achieved.
5
0x0020
DEBUG_H2H_DATA
HUB Ver >= 30.4.0: MSG from HUB-2-HUB module
when DATA is relayed between HUBs.
6
0x0040
DEBUG_PA_CTRL
RT Ver >= 31.0.0: MSG from Protocol-Adapter
module when new line, RTU, etc is configured.
7
0x0080
DEBUG_PA_DATA
RT Ver >= 31.0.0: MSG from Protocol-Adapter
module when PA-DATA is received and sent.
8
0x0100
DEBUG_MIL
Ver >= 30.8.0: MSG from Multi Inbound Link (MIL)
functions.
9
0x0200
DEBUG_RT_POWER_SAVE
Ver >= 31.1.0: MSG when Power-Save (LISTEN).
10
0x0400
DEBUG_TC
Ver >= 31.3.0: MSG when from Text-Command
(TC)
11
0x0800
n/a
12
0x1000
n/a
13
0x2000
n/a
14
0x4000
n/a
15
0x8000
n/a
16
0x0001.0000
n/a
17
0x0002.0000
n/a
18
0x0004.0000
n/a
19
0x0008.0000
n/a
20
0x0010.0000
n/a
21
0x0020.0000
n/a
22
0x0040.0000
DEBUG_TX_FREQUENCY_
ADJUST_RX_2150
HUB Ver >= 31.1.0: MSG when AFA is receiving
packets from RTs.
23
0x0080.0000
DEBUG_TX_FREQUENCY_
ADJUST_TX_2150
HUB Ver >= 31.1.0: MSG when AFA is sending
frequency adjustment to RTs.
