3.1.18 PORT_STREAM_RT [n]
Default –1, Range –1…12287 (0x2FFF)
• Not Used when PORT_TYPE [n] is SERVICE.
In this case, RT-Address is included in received packets from NMS.
• Used when
PORT_TYPE [n] is STREAM, ADAPTER or NETWORK.
All User-Data received from this PORT will be sent to the indicated Unit(s).
Value Hex Description
HUB .
–1 0xFFFF.FFFF
IP Routed Line in HUB Ver >= 30.4.0
0 0x0000 BROADCAST – I.e. ALL RTs.
1 … 4095 0x0001 … 0x0FFF RT 1 … RT 4095.
4096 0x1000 n/a – CLUSTER 0 isn’t defined.
4097 …8191 0x1001 … 0x1FFF
CLUSTER Address 1 … 4095.
That is all RTs with NET_FIRST_POLL_RT equal lower 12 bits
(0x0FFF) of
PORT_STREAM_RT.
8192 0x2000 n/a – GROUP 0 isn’t defined.
8193 … 8292 0x2001 … 0x2064
GROUP Address 1 … 100.
That is all RTs that are member of the GROUP defined by the
lower 12 bits (0x0FFF) of
PORT_STREAM_RT.
An RT can be member of max 5 GROUPs.
Membership is defined by
NET_GROUPS [1…5].
8293 … 12287 0x2065 … 0x2FFF
GROUP Address 101 … 4095.
n/a – Highest GROUP Address is 100.
Use
PORT_STREAM_RT and PORT_STREAM_RT_PORT [n] to define Leased Lines:
• HUB Ù RT Leased Line
See next page.
• RT Ù RT Leased Line
RT:
PORT_STREAM_RT = RT, BROADCAST, GROUP or CLUSTER.
PORT_STREAM_RT_PORT = PORT(s) at remote RT.
• LOCAL Leased Line
HUB:
PORT_STREAM_RT = HUB.
PORT_STREAM_RT_PORT = PORT(s) at local HUB.
RT: PORT_STREAM_RT = NET_RT_ADDRESS.
PORT_STREAM_RT_PORT = PORT(s) at local RT.
Note: Just for fun, it’s possible to route User-Data from one PORT to other PORT(s) within
the same local Unit. Why should you do this?
