TSAT 3000 Configuration Parameter Description, January 2013 Page 77 of 124
3.11.8 PHL_IN_OUT_PACKET_RATIO
Default 1, Range 1…64
Set the ratio between Inbound and Outbound packets. I.e. the RTs may be told to send several
packets to HUB (inbound) for each
packet they receive from HUB (outbound).
Note 1: Currently, the value must be 1 for correct operation.
Note 2: DSP will be restarted 10 seconds after you’ve changed CURRENT value.
Ver >= 30.8.0: Restart of DSP is enabled by bit 2 (0x0004) in
UTL_UTILITY_MASK.
3.11.9 PHL_DSP_OPTIONS
Default 0, Range 0…0xFFFF.FFFF
Ver <= 30.1.0
Not Implemented.
Ver >= 30.1.1
Bit field for test and debugging of DSP. It’s included in the DSP Configuration message.
Bit Mask Description CCU version DSP version
0
0x0000.0001
TX Spectrum flip 30.5.0 2.2.0
1
0x0000.0002
RX Spectrum flip 30.5.0 2.2.0
2
0x0000.0004
TSAT 2150 Compatibility 30.8.0 2.4.0
3
0x0000.0008
TSAT 2150 Dummy Symbols 2.4.1
4 … 29
0x3FFF.FFF0
Not Used
30
0x4000.0000
Disable RX data ?
31
0x8000.0000
Disable TX data ?
Note 1: CCU version >= as indicated in table, will initialize the lower bits according to other
configuration parameters. By also setting these bits in
PHL_DSP_OPTIONS, the XOR
result will be passed on to the DSP.
Note 2: DSP will be restarted 10 seconds after you’ve changed CURRENT value.
Ver >= 30.8.0: Restart of DSP is enabled by bit 2 (0x0004) in
UTL_UTILITY_MASK.
