TSAT 3000 - Telemetry and data transfer via SATellite
TSAT 3000 Configuration Parameter Description, January 2013 Page 2 of 124
Document Status
Product description: Hub Station and Remote Terminal Configuration Parameter Description
Revision Date CCU Ver Reason for change
1 2007.11.01 30.1.1 First Revision.
2 2008.02.12 30.2.0 Changed UTL_UTILITY_MASK (UTILITY_CCU_LISTEN_TO_CCU).
New
DAC_TCXO_REF
New
DAC_OCXO_REF
Changed
UTL_UTILITY_MASK (UTILITY_ADJUST_TCXO)
Rearranged chapters (ADC / DAC Parameters)
Described ADC + DAC Parameters (New drawing)
Renamed
ADC_3_TXCO_VOLTAGE to ADC_3_TCXO_VOLTAGE
Removed
IP_SUBNET_MASK_{ETH1 | ETH2 | SAT}
Renamed IP_ADDRESS_{ ETH1 | ETH2 | SAT } to …_{ LANA | LANB | SAT }
Described PORT_STREAM_RT (GROUP + CLUSTER Leased Line)
Described
PKT_INBOUND_SIZE (Min size of POLL_ACK: 16 => 24)
Changed
UTL_DEBUG_MASK (DEBUG_ADDR + DEBUG_SWUL)
Described
LCC_{MIN | MAX}_RETRANS_DELAY (Note)
Changed
IP_ROUTE.
3 2008.04.22 30.3.0 Changed UTL_DEBUG_MASK (DEBUG_PPR).
Changed
PHL_SLOT_PHASE_MODE (PPR is implemented).
Described
NET_RT_ADDRESS (Ref. PPR)
Described
PKT_OUTBOUND_SIZE (Ref. PPR)
Described
PKT_INBOUND_SIZE (Ref. PPR)
Changed
PHL_INBOUND_GUARDPERIOD (Auto Default value).
New
NET_NAME
Changed GAIN_END2END_TAGET (DELTA 0.5 => 0.3 dB).
4 2008.05.06 30.3.1 Changed UTL_UTILITY_SEARCH_MASK (KEEP_LOCK_FOREVER).
Described
PORT_PKT_TIMEOUT (Corrected error)
Described
GAIN_TX_END2END_TARGET (DELTA 0.3 => 0.2 dB)
Changed
UTL_UTILITY_MASK (TEST_GAIN_WITH_MANY_RTS).
5 2008.07.03 30.4.0
30.4.1
Described GAIN_TX_END2END_TARGET (Threshold 1 => 2 packets)
Changed
PKT_MAX_SIZE (Minimum 100 => 256)
Changed
PHL_SLOT_PHASE_DELAY (Auto function implemented)
New
SWITCH_{RX | TX}_XXX
Changed SOCK_OPTIONS (DEBUG_PRINT_{RX | TX})
New
UTL_DEBUG_MASK_B
Described PKT_INBOUND_SIZE (IP-address in POLL_ACK)
Changed
PORT_STREAM_RT (Value -1 is IP Routed Line)
6 2008.10.08 30.5.0 Described SYS_IS_HUB (Cannot change via satellite)
Described
UTL_UTILITY_MASK (Cannot change via satellite)
Changed
PHL_TX_HUB_FREQUENCY (C-band range)
Changed
PHL_TX_RT_FREQUENCY (C-band range)
Changed
PHL_TX_HUB_FREQUENCY_BKUP (C-band range)
Changed
PHL_TX_RT_FREQUENCY_BKUP (C-band range)
Changed
PHL_TX_RT_FREQUENCY_2 (C-band range)
Changed
PHL_TX_RT_FREQUENCY_2_BKUP (C-band range)
Changed
PHL_{OUTBOUND | INBOUND}_IDENTITY (Changed Default value)
Changed
PHL_{OUTBOUND | INBOUND}_IDENTITY (Changed Default value)
Changed
PHL_FE_{RX | TX}_LO (C-band range)
Described
PHL_SLOT_PHASE_SETPOINT (1 symbol => ¼ symbol)
Changed
GAIN_TX_REF (Limits)
Renamed
GAIN_TX_END2END_DAC_{MIN | MAX} => GAIN_TX_DAC_{MIN | MAX}
Changed UTL_MIRROR_CHANNEL (101 = Tx RF Level)
Changed
UTL_UTILITY_SEARCH_MASK (RT_CLEAN_CARRIER)
Changed
UTL_DEBUG_MASK (DEFAULT 0x170F)
Described
PHL_DSP_OPTIONS (Rx/Tx Flip)
