Unipulse F701+ User Manual

114
6 Useful Functions
114
Useful Functions
Chapter
6
○ Status 3 (weighing information, LOCK status)
- Decimal place (2-bit binary: 0 to 3) Indicates decimal place of F701+ (setting mode 3-7).
- Units display (4-bit binary: 0 to 4) Indicates units display of F701+ (setting mode 3-7).
- STAB Turns ON when the weight value is stable.
- HOLD Turns ON during weight value hold.
- TARE ON while the tare subtraction is being performed.
- NET ON while net weight
is being displayed and OFF while gross weight is being
displayed.
- ZT ON when the zero tracking function is operating.
- LOCK(SW) ON if LOCK SW on the rear panel is ON and OFF if it is OFF.
- LOCK (setting) (2-bit binary: 0 to 3) Indicates setting LOCK of F701+ (setting mode 2-9).
○ Command bit response
- Gross weight/net weight Returns the same status as the gross weight/net weight display switch
display switch response in the command bit.
- One-touch tare subtraction Turns ON after receiving and performing one-touch tare subtraction in
response the command bit. Turns OFF after confirming that one-touch tare
subtraction in the command bit is OFF.
- One-touch tare subtraction Turns ON after receiving and performing one-touch tare subtraction
reset response reset in the command bit. Turns OFF after
confirming that one-touch
tare subtraction reset in the command bit is OFF.
- Digital zero response Turns ON after receiving and performing one-touch tare subtraction in
the command bit. Turns OFF after confirming that digital zero in the
command bit is OFF.
- Digital zero reset response Turns ON after receiving and performing digital zero reset in the
command bit. Turns OFF after confirming that digital
zero reset in the
command bit is OFF.
- Hold response Returns the same status as hold in the command bit.
- Accumulation clear response Turns ON after receiving and performing accumulation clear in the
command bit. Turns OFF after confirming that accumulation clear in
the command bit is OFF.
- Accumulation command Turns ON after receiving and performing an accumulation command in
response the command bit.
Turns OFF after confirming that the accumulation
command in the command bit is OFF.
- Start response Turns ON after receiving and performing a start signal in the command bit.
Turns OFF after confirming that the start signal in the command bit is OFF.
- Stop response Turns ON after receiving and performing a stop signal in the command bit.
Turns OFF after confirming that the stop signal in the command
bit is OFF.
- Pause response Turns ON after receiving and performing pause in the command bit.
Turns OFF after confirming that pause in the command bit is OFF.
- Judging input response Turns ON after receiving and performing judging input in the
command bit.
Turns OFF after confirming that judging input in the command bit is OFF.
- Zero calibration response Turns ON after receiving and performing zero cali
bration in the
command bit. Turns OFF after confirming that zero calibration in the
command bit is OFF.
- Span calibration response Turns ON after receiving and performing span calibration (actual load
(actual load calibration) calibration) in the command bit. Turns OFF after confirming that span
calibration (actual load calibration) in the command bit is OFF.
