Unipulse F701+ User Manual

113
6 Useful Functions
113
Useful Functions
Chapter
6
- CZ Turns ON when at the actual zero point (0±1/4 scale division). Please note that when the
1/4 scale division (setting mode 3-7) is set to ON, it also turns ON at the center point of
each indicated scale interval.
- ▼ Turns ON when it is at +1/4 scale division from the center point of each indicated scale
interval. Please note that it is necessary to set the 1/4 scale division (setting mode 3-7) to
ON.
- Over Displays OFL3 (gross weight > gross over setting value) for gross weight
and OFL1 (net
weight > net over setting value) for net weight.
- Sign Turns ON when the target weight value is a negative value.
○ Read data (32-bit binary without sign)
Indicates data specified by the command no. Signs are not included. Please note that when performing
command no. 19 (read tare value), the format will be the same as the 1st to 4th words (in this case, over
is when tare > 99999). The da
ta indicated here are updated each time the ON edge of a command
request is received. The order of HI and LO positions changes with the DWORD mode of F701+
(setting mode 6-1).
○ Status 1 (error information)
- Sequence error (4-bit binary: 0 to 9) Indicates sequence error no. 0 means no error.
- Calibration error (4-bit binary: 0 to 9) Indicates the calibration error no. 0 means no error.
- Calibration in
process Turns ON during zero calibration or span calibration.
- ZALM Turns ON with ZALM generation when the total weight for digital zero
exceeds the DZ regulation value as a result of digital zero or zero tracking
operation.
- +LOAD Turns ON when a signal that exceeds the F701+ signal input range is
input.
- -LOAD Turns ON when a signal that falls below the F701+ signal input range is
input.
- OFL2 Turns ON
when the gross weight > capacity + 9 scale divisions.
○ Status 2 (weighing information)
- HI LIM Comparison timing depends on the setting for HI/LO limit comparison mode, but it
normally turns ON when the weight value > upper limit setting value.
- LO LIM Comparison timing depends on the setting for HI/LO limit comparison mode, but it
normally turns ON when the weight value < lower limit setting value.
-
HI Comparison timing depends on the setting of over/under comparison mode, but it
normally turns ON when the weight value > (final + over).
- GO Comparison timing depends on the setting for over/under comparison mode, but it
normally turns ON when (final - under) ≦ weight value ≦ (final + over).
- LO Comparison timing depends on the setting for upper/under comparison mode, but it
normally turns ON when th
e weight value < (final - under).
- SP1 Turns ON when the weight value ≧ (final - set point 1) during weighing.
- SP2 Turns ON when the weight value ≧ (final - set point 2) during weighing.
- SP3 Turns ON when the weight value ≧ (final - compensation) during weighing.
- NZ Comparison timing depends on the setting for near zero comparison mode, but it
normally turns ON when the weight value ≦ near zero.
- CO
MPL. Turns ON during complete signal output.
