 Command Formation
: Command format = '[' + 'prefix' + '_' + 'command' + '_' + 'parameter' + ']'
Ex) [SPM_CTCX_0123]
[
Prefi
x _
Comman
d _
Paramet
er ]
‘[‘= Start symbol
‘prefix’ = 3 letters arrangement.
First letter: Send / Echo
Second letter: Pc / Mcu / Lcd / Optic
Third letter: Pc / Mcu / Lcd / Optic
Ex) SPM: Send PC to MCU, SLP: Send LCD to PC, SMO: Send MCU to OPTIC,
EPM: Echo SPM, ELP: Echo SLP, EPO: Echo SPO
‘Command’ = 4 letters arrangement. If it is less than 4 letters, the command should be filled
up with “_”.
Ex) [SPM_CT__]
‘Parameter’ = only when commands come with parameter, 4~5 letters arrangement.
If they are less than 4 or 5 letters, the parameter should be filled up with “0”.
Ex) In case of 4 letters parameter- [SPM_XPST_0234]
In case of 5 letters parameter- [SPM_COAX_ 00100]
In case of 4 letters parameter only with “0”- [SMP_STOP_0000]
']' = End symbol
SPM,
EPM
SLP
SMO
CT__,
PANO
CEPH,
CTCX
4 digit number or
5 digit number
Ex)0123,12345
