4.3. Handle Frame Unit Part
 DISASSEMBLY OF THE HANDLE FRAME TOP COVER
By doing this, you can access:
- SUB027 BOARD
 DISASSEMBLY OF THE CHINREST TOP COVER
By doing this, you can access:
- SUB017 BOARD
