Smart Plus (PHT-35LHS)
Technical Manual
VT-TECH-Smart Plus-001
26 / 188
COPYRIGHT© 2018 VATECH.
ALL RIGHTS RESERVED
 DISASSEMBLY OF THE ROTATOR LOWER COVER
By doing this, you can access:
- INVERTER BOARD, SUB029 BOARD
Disassemble the ROTATOR LOWER COVER in the sequence as shown below.
