Smart Plus (PHT-35LHS)
Technical Manual
VT-TECH-Smart Plus-001
COPYRIGHT© 2018 VATECH.
8) If the standard is met, do the steps that follow and do the steps 1) through 8) again.
To adjust the X value,
① Type [SPM_AX?_] and click Send to read the current X-axis position.
② Type [SPM_AXST_####] and click Send to adjust X axis position.
To adjust the Y value,
① Type [SPM_AY?_] and click Send to read the current Y-axis position.
② Type [SPM_AYST_####] and click Send to adjust Y-axis position.
• When you change AXST, AYST value by 10, it will be changed by approximately
5 pixels.
• To increase X value, decrease AXST value.
• To increase Y value, increase AYST value.
To make the cross-line level,
① Open reconstruction.vxm.
② Change STARTANGEL value (default: 0.0) under Geometry section.
ex) To tilt the angle by 1° clockwise, type 1,
To tilt the angle by 1° counterclockwise, type 359.
③ Save reconstruction.vxm file and exit.
