Communication Interfaces
VTK-TR-BA-072e-1 - User Manual MDS 358X Series
49 STRIGGER:ASET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
This command is used to modify pulse parameters without transmitting
the trigger signal. The values for both of the parameters “Falling” and
“Rising” are specified in steps of 0.01 ms. Minimum value for “Falling” is
0.01 ms, for “Rising” 0.01 ms. But the minimum values for Falling and Rising
also always depend on the current Needle Lift % (see
paragraph 7.4,
page 66).
All other time parameters are entered in units of 1/10 ms.
Specified values must be integer and positive. To choose the external
mode, enter “EXTERNAL” for “Open Time”, instead of a numerical value.
You have to include all six setup parameters.
The start of a dispensing cycle with the selected parameter configuration is
initiated by the command “VALVE:AOPEN”.
This command works just like its “TRIGGER” variant. Only the MDC does not
answer with “OK”, but with the saved parameters instead. This way the
machine software can check directly, if the parameters were received
correctly.
Information:
With this command, the information is only held in the RAM and therefore
gets lost, once the system is switched OFF. If that is a problem, use the next
command instead. (The difference in the command line is the “1” at the
STRIGGER:ASET:55,10,8,80,20,8
The following values are assigned to the dispensing
parameters:
Rising: 55 ≙ 0.55 ms (ms = Millisecond)
Open Time: 10 ≙ 1.0 ms
Falling: 8 ≙ 0.08 ms
Needle Lift: 80 %
Number of Pulses: 20
