Error Messages
VTK-TR-BA-072e-1 - User Manual MDS 358X Series
11.3 Status Messages
The following table lists all the status messages you could encounter when using this system (see
Tab. 32). Status messages can appear while you plug IN or OUT a heater or a cooling valve, as well
as in connection with the calibration of a heater (see paragraph 7.13.2, page 77).
INFORMATION
Status messages are not stored
Status messages disappear after approx. 2 s from the display. They are not saved. A special case is
a calibration gone wrong. Then you get three times in a row the alternating messages “Wrong
calibration” and “Please try again!”, separated by approx. 1.5 s.
Status message Concerns Notes
Cooling valve connected successfully
Cooler could not be activated
Cooling valve could not be activated (e.g. because the
flow control valve is not connected correctly or because
the wrong device is connected)
Cooling valve was disconnected during operation
Heater connected successfully
Heater could not be activated
Heater could not be activated (e.g. because the heater
is not connected correctly or because the wrong device
Heater was disconnected during operation
Calibration was not finished successfully (e.g. because
calibrator was connected twice). Please try again.
Calibration of the heater (or of heater
cooling) not
Tab. 32: List of status messages
