VersaMed iVent201 - Ventilation Performance and Controlled Parameters

Introduction
16
1.6.7 Ventilation Performance and Controlled
Parameters
Respiratory Rate 1 – 12 ±1, 12 – 80 ± 2 bpm
Tidal Volume 50-2000 mL
Accuracy of Tidal
Volume Delivery
±10% or ±10 mL whichever is greater
Accuracy of Respiratory
Volume Measurement
±15% above 100 mL from actual reading
or ±10 cc below 100 mL
Inspiratory Pressure
Limit
5 to 80 ±5 cmH
2
O
Inspiratory Time Adaptive Time
TM
or 0.2 to 3 ±10% sec
Peak Flow (PIF)
Adaptive Flow
TM
or to 120 ±10% L/min
Spontaneous to 140 ±10% L/min
Oxygen Mix (FiO
2
) 21% to 100% ±5% O
2
PEEP
0 to 40 ±1 cmH
2
O or ±10%, whichever is
greater
Trigger Sensitivity 1 to 20 L/min Flow, Off
- 0.5 to – 20 cmH
2
O Pressure, Off
PSV 0 to 60 ±10% cmH
2
O
Positive Pressure Relief
Valve
80 cmH
2
O
Controlled Pressure 5 to 80 cm ±5 cm
FiO
2
at Power up 21%, 40%, 60%, 100% (configurable)
Purging Cycle 1, 2, 5, 10 minutes, Off (configurable)
