iVent201 Operator's Manual
47
figure 2.13 Nebulizer connected icon
2. Install the Nebulizer with the
desired medication to the
patient circuit after the Wye and
the flow sensor, without or after
the HME filter.
3. Connect the other side of the
Nebulizer tube to the Nebulizer.
2.4.5 Pulse Oximeter
A pulse oximeter can be connected to the iVent
201
ventilator
allowing the operator to continuously monitor patient’s
oxygenation saturation on the iVent screen.
Warnings
Use only Nonin manufactured pulse oximeter sensors.
Using other manufacturer’s sensors can result in
improper oximeter performance.
Explosion Hazard: Do not use the pulse oximeter in an
explosive atmosphere or in the presence of flammable
anesthetics or gasses.
Carefully route cables and connections to reduce the
possibility of entanglement and strangulation.
The SpO2 device do not meet defibrillation-proof
requirement per IEC 60601-1.
Do not sterilize the SpO2 device. Refer to the cleaning
instructions included in the sensor instruction.
Do not use the pulse oximeter in the MRI environment.
