2.9.3 The Screen
The LCD screen is organized to allow rapid access to all of the
ventilator’s functions. Monitoring or control of any critical
parameter is never more than a couple of clicks away.
• Baseline indicators and alarms – emergency
alerts and alert status indicators, power and
battery state, date and time, and the Menu
access button -- are displayed along the
bottom of the screen indicators.
• Set values are displayed in black
• Measured and calculated values are displayed
in blue -- flashing values indicate that a set
value was not obtained.
Here is a quick overview of the most important screens:
The Main Screen (Figure 2.19) is the first screen displayed
when the iVent
201
is placed in Standby or Start Mode.
The slider gauge along the left side of the screen displays the
real-time measured Peak Inspiratory Pressure below a digital
readout of the last peak inspiratory pressure value.
On the top left portion of the screen, a large box shows the total
measured respiratory rate in breaths per minute in large blue
numbers. The selected/default respiratory rate is shown in
smaller black numbers below. Selecting the Respiratory Rate
box enables changing the number of breaths per minute.
