iVent201 Operator's Manual
41
To connect a patient circuit:
1. Twist the knurled, light-blue
connector of the inspiratory
limb onto the main hose
connector. The connector
should fit snugly.
2. Connect the first flow sensor
tube – closer to the end of the
patient Wye, to the left male
luer inlet of the ventilator by
pushing the opening of the tube
inside the inlet and twisting it
clockwise until it is locked in
place. (Notice that the bayonet-
style male luer is different from
the screw-fitting female luer
mount of the second sensor
inlet.)
3. Connect the other flow sensor
tube to the second sensor inlet
of the ventilator by twisting the
knurled end of the tube onto the
luer lock.
4. Fasten the blue Expiratory
Valve Control Line to the female
luer connector on the right side
of the ventilator, marked with a
blue dot, by twisting the
knurled end piece of the tube
onto the inlet.
