Setting Up
44
3. Connect the one-way valve to
one end of a 1-2’ length of
22mm corrugated tubing.
4. Connect the other end of the
tubing to the ventilator outlet.
Now, fasten the one-way valve
to the humidifier inlet. Be sure
the directional arrow on the
valve is pointing towards the
patient end of the circuit.
5. Connect the male and female
clear sensor tubing connectors
to the male and female luer
inlets on the front of the iVent
201
as described above in section
2.3. Connect the blue expiratory
sensor tube to the luer
connector marked with a blue
dot on the front of the
ventilator.
