FIG. 173
FIG. 174
FIG. 175
18. Tighten the screw to fix the spindle using the
torque screwdriver.
19. Plug the spindle cable into the spindle connector.
20. Tighten the spindle cable by manually turning the
knurled nut clockwise.
21. Insert the collet chuck release unit cable into the
corresponding connector in the machine.
FIG. 176
Original Operating Instructions:E5
Version: 4/27/2023
Maintenance
EN 70
