Vodavi Starplus DHS - M1-50 Wiring Designations for the 3 X 8 Modules

DHS-E Installation 3-23
Table 3-12: 66M1-50 Wiring Designations for the 3 x 8 Modules
Cable
Pair
Pair Color Designation
3 x 8 Modules
1st 2nd 3rd 4th 5th 6th
26/1 White/Blue N/C
27/2 White/Orange CO Line / Port 3 CO 3 CO 6 CO 9 CO 12 CO 15 CO 18
28/3 White/Green CO Line / Port 2 CO 2 CO 5 CO 8 CO 11 CO 14 CO 17
29/4 White/Brown CO Line / Port 1 CO 1 CO 4 CO 7 CO 10 CO 13 CO 16
30/5 White/Slate N/C
Do not use these
pairs for any reason.
Electrical damage
may occur.
31/6 Red/Blue N/C
32/7 Red/Orange N/C
33/8 Red/Green N/C
34/9 Red/Brown N/C
35/10 Red/Slate N/C
36/11 Black/Blue N/C
37/12 Black/Orange N/C
38/13 Black/Green N/C
39/14 Black/Brown N/C
40/15 Black/Slate N/C
41/16 Yellow/Blue N/C
42/17 Yellow/Orange N/C
43/18 Yellow/Green Station Port 1 STA
100
STA
108
STA
116
STA
124
STA
132
STA
140
44/19 Yellow/Brown Station Port 2 STA
101
STA
109
STA
117
STA
125
STA
133
STA
141
45/20 Yellow/Slate Station Port 3 STA
102
STA
110
STA
118
STA
126
STA
134
STA
142
46/21 Violet/Blue Station Port 4 STA
103
STA
111
STA
119
STA
127
STA
135
STA
143
47/22 Violet/Orange Station Port 5 STA
104
STA
112
STA
120
STA
128
STA
136
STA
144
48/23 Violet/Green Station Port 6 STA
105
STA
113
STA
121
STA
129
STA
137
STA
145
49/24 Violet/Brown Station Port 7 STA
106
STA
114
STA
122
STA
130
STA
138
STA
146
50/25 Violet/Slate Station Port 8 STA
107
STA
115
STA
123
STA
131
STA
139
STA
147
