Port Numbering 5-15
Operation
When a page announcement is heard:
1. Lift the handset
2. Dial [#] + [5] + [9]
Port Numbering
Description
Adding SLT stations to the DHS/DHS-E has the significant advantage of port-gain. When
the SLT interfaces are installed (2-Port Analog Adapter and 2-Port SLT Expansion), the
station numbering and available station ports are expanded at a ratio of 2-to-1. When
analog adapters and expansions are installed, the port numbering is as follows:
Table 5-2: SLT Port Numbering (DHS)
Card 1 Card 2 Card 3
Digital
Port
B1 Sta
Number
B2 Sta
Number
Digital
Port
B1 Sta
Number
B2 Sta
Number
Digital
Port
B1 Sta
Number
B2 Sta
Number
01 10 58 09 18 66 17 26 74
02 11 59 10 19 67 18 27 75
03 12 60 11 20 68 19 28 76
04 13 61 12 21 69 20 29 77
05 14 62 13 22 70 21 30 78
06 15 63 14 23 71 22 31 79
07 16 64 15 24 72 23 32 80
08 17 65 16 25 73 24 33 81
To Next Page
