6-28 Call Handling Configuration
There are three data fields associated to CO Line Preset Call Forward
CO P-FWD TIME—One timer referenced by all CO lines set for Preset Forward.
COxx DEST—Destination set for the CO line being programmed.
COxx VMID—A 6-digit field that can be programmed with a digit string used when
the forward destination is a VM type Hunt Group. This digit string can be used to
divert the CO caller to the correct voice mail menu prompt. There is a COxx VMID field
for each CO line.
Default
The DHS/DHS-E default settings of associated CO Line Preset Call Forward data fields are
listed below:
CO P-FWD TIME = 16
CO XX DEST = Empty
CO XX VMID = Empty
Programmable Range
CO Line Preset Forward data fields:
CO P-FWD TIME = 6/10/16/22/30/40 sec
DHS CO XX DEST = 10-81 stations, 82-89 Hunt / VM Groups
DHS-E CO XXX DEST = 100-195 stations, 800-807 Hunt / VM Groups
CO XX VMID = 000000-999999
Wait (ICLID)
This timer is required to ensure that data sent from the phone company is received
before the phone system starts ringing.
Default
The DHS/DHS-E Wait ICLID timer is set for 4.0 sec, and is variable from 3.5/4/4.5…7.0 sec.
VM Monitor Time
The DHS/DHS-E enables the user of any DHS/DHS-E key telephone to monitor callers
leaving a message in their voice mail box. When a caller is routed from a ringing
telephone to a user voice mail box, an alert is presented to advise the user that the
feature can be invoked.
Default
The DHS/DHS-E VM Monitor Time is set for 6 sec, and is variable at 10/20/30/40/50/60 sec.
If you are not consistently getting caller ID data, set this timer to 7.0 sec.
