Vodavi Starplus DHS - Dialing Specifications; FCC Registration Numbers; Maximum Cable Length

DHS Technical Specification Tables 2-19
Table 2-6: Maximum Cable Length
Digital Key Telephone
(Distance measures in linear ft. of cable from KSU
to DKT.)
26 AWG - (850 ft) 255 m
24 AWG - (1416 ft) 425 m
22 AWG - (1983 ft) 700 m
Standard SLT
(Distance measures in linear ft. of cable from KSU
to SLT. 2-Port CO Module may be placed anywhere
in between.)
26 AWG - (650 ft) 195 m
24 AWG - (1133 ft) 340 m
22 AWG - (1586 ft) 476 m
Table 2-7: Dialing Specifications
DTMF Dialing mode:
Frequency deviation
Rise time
Duration of DTMF signal
Inter-digit time
VM Port DTMF duration
VM Port Inter-digit time
+
1%
3ms
programmable 50-150ms (70ms default)
programmable 50-150ms (70ms default)
programmable 60-150ms (120ms default)
programmable 60-150ms (120ms default)
Pulse Dialing mode:
Pulse dial rate
Pulse Make/Break ratio
10 pulses per second
60/40
Table 2-8: FCC Registration Numbers
For systems configured for Key System operation (each CO
line appears on its own dedicated button).
D6XTAI-23085-KF-E
For systems configured for hybrid operation (CO lines may
be accessed by dial codes and Pool/Loop buttons).
D6XTAI-23086-MF-E
