9.1.6 Actuators in the channel
If needed, you can call up details on the actuators of a channel. Proceed as
follows.
Button Action/result
In the main menu, select the [System] menu and press ok.
The [System] menu opens.
Select the [Products] menu here and press ok.
The [Select product type] menu opens.
Using the selection cursor, select the product type of the
channel for whose actuators you wish to display information
and press ok.
All channels of the selected product type are displayed.
Using the selection cursor, select the desired channel and
press ok.
The context menu for the channel is displayed.
Using the selection cursor, select the
[Actuators in channel] menu item.
Call up the function with ok.
The following menu contains all actuators of the selected
channel.
Select the desired actuator and confirm with ok.
Detailed information on the actuator is displayed.
The arrow buttons can be used to scroll through the informa-
tion to all actuators in the channel.
Main menu
System
Products
Product type
Channel x
Actuators in channel
System
