WEG MVW01 - Mechanical Data

3
MVW01 WITH 3 LEVELS (3L)
3.1 MECHANICAL DATA
3.1.1 Panel Constructive Aspects
L
R
L
I
L
C
P
H
L
Figure 3.3: Panel Constructive Aspects
The MVW01 line is assembled in panels with the dimensions shown in Table 3.1 on page 3-3 :
Table 3.1: Mechanical data (dimensions in mm)
Frame size
L
R
(mm) L
I
(mm) L
C
(mm) L (mm) H (mm) P (mm)
Weight (kg)
A0
- - -
1000 2316 1000 900
A
600/800
(1)
1280 600
2480/2680
2226
980
1560
B
800/1280
(2)
1280 600
2680/3160
1700
C
800/1280
(2)
2 x 1280 800
4160/4640
2700
D
(5)
1280/2x1280
(3)
3 x 1280 800
5920/7200
1000
4500
E
(5)
1280/2x1280
(4)
4 x 1280 800
7200/8480
5000
2 x D
(5)
1280/2x1280
(3)
3 x 1280 800
5920/7200
2 x 1000
9000
2 x E
(5)
1280/2x1280
(4)
4 x 1280 800
7200/8480
10000
Tolerance for all dimensions ± 10 mm.
(1) 800mm: With 24 pulse rectifier.
(2) 1280mm: With 24 pulse rectifier.
(3) 2x1280mm: With 18 pulse rectifier (above 1420A) or with 24 pulse rectifier.
(4) 2x1280mm: With 18 or 24 pulse rectifier.
(5) Mechanics D and E with 18 or 24 pulse rectifier, consider + 800 mm for additional column of input and output cables.
MVW01 | 3-3
