2
GENERAL INFORMATION
2.3 HOW TO SPECIFY THE MVW01 MODEL
Product Line
MVW01 - Standard Series
Output Rated
Current (ND)
Diode input rectifier
H20 - 12 pulse
H30 - 18 pulse
H40 - 24 pulse
H60 - 36 pulse
RB - AFE / Regenerative
Model
G3 - Generation 3
WC - Water-cooled
EV - Evaporative cooler
MVW01 3648 T4160 E H20 G3 _ z
Rated
voltage
T2300
T3300
T4160
T6300
T6900
Language
P - Português
E - English
S - Spanish
Options
DN - DeviceNet
PD - Profibus
ET - Ethernet
A1 - EBA board
B1 - EBB board
LR - Laod reactor
DF - Filter dv/dt
SF - Sinusoidal filter
End of Code
MVW01C - Compact Series
G2 - Generation 2
Figure 2.1: Product code
(1) For all available models check from Table 2.2 on page 2-6 to Table 2.7 on page 2-11 .
POWER SUPPLY
Voltage 2300, 3300, 4160, 4600 or 6900 V
Frequency 48.5 to 61.8 Hz
Voltage imbalance be-
tween phases
<3 %
Cos φ >0,97
AUXILIARY SUPPLY
Voltage 220, 380, 400, 415, 440, 460, 480, 525, 550, 575 or 690 V
Frequency 48.5 to 61.8 Hz
Voltage imbalance be-
tween phases
<3%
PROTECTION
DEGREE
Standard IP21
Optional IP41 and IP42
DIMENSION Width / Height / Depth
(mm)
15 distinct frame sizes. Consult Section 3.1 MECHANICAL DATA on page 3-3 , Sec-
tion 4.1 MECHANICAL DATA on page 4-2 , Section 5.1 Mechanical data (dimensions
in mm) on page 5-2 , Section 6.6 MECHANICAL DATA on page 6-9 .
ENVIRONMENTAL
CONDITIONS
Temperature 0 to 40 °C (up to 50 °C with 2.5 % reduction in the output current/ °C)
Humidity 5 to 90 % without condensation.
Altitude 0 to 1000 m (up to 4000 m with 10 % reduction in the output current / 1000 m)
Pollution degree 2
FINISHING Color
Gray ultra dull (Doors).
Gray RAL 7035 (Base, Roof, Shutters).
MVW01 | 2-2
