11
OPTIONAL ACCESSORIES AND BOARDS
P101 = 0,5 (Deceleration time);
P121 = 57,4 (Output frequency);
P206 = 3 (Auto-reset time);
P222 = 0 (Remote speed reference);
P263 = 0 (DI1 Digital input);
P264 = 0 (DI2 Digital input);
P265 = 4 (DI3 Digital input);
P266 = 6 (DI4 Digital input);
P297 = 10 kHz (Switching frequency).
11.5 MVC3 CONTROL BOARD CONNECTIONS
Figure 11.21: MVC3 board connections
MVW01 | 11-20
