11.2 FUNCTION EXPANSION BOARDS
The function expansion boards increase the MVC4 control board functions. There are 3 expansion boards available and their selection depends
on the application and the desired functions. The three boards cannot be used simultaneously. The difference between the EBA and EBB
boards is in the analog inputs/outputs. The EBC1 board serves for the encoder connection; however, it does not have its own power supply
as do the EBA/EBB boards. Next, the detailed description of those boards is presented
11.2.1 EBA (Expansion Board A - I/O)
The EBA board can be supplied in different configurations, created from the combination of specific functions.
The available configurations are shown in the table below.
Table 11.5: EBA card versions and functions available
Functions EBA.01-A1 EBA.02-A2 EBA.03-A3
Differential input for incremental encoder with 12 V/200 mA, isolated internal power
supply, feedback for speed regulator, digital speed measurement 14 bit resolution,
(100 kHz maximum signal frequency).
Available Not available Not available
Buffered encoder output signals: isolated input signal repeater, differential output,
available to external 5 V to 15 V power supply.
Available Not available Not available
1 Differential analog input (AI4): 14 bits (0.006% of the range [+-10 V]), two-pole: -10
V to +10 V, (0 to 20) mA / (4 to 20) mA, programmable.
Available Not available Available
2 Analog outputs (AO3/AO4): 14 bits (0.006% of the range [+-10 V]), two-pole: -10 V
to +10 V, programmable.
Available Not available Available
Isolated RS-485 serial port. Available Available Not available
Digital Input (DI7): isolated, programmable, 24 V. Available Available Available
Digital input (DI8) with special function for motor thermistor (PTC): actuation 3,9 kΩ,
release 1,6 kΩ.
Available Available Available
2 isolated Open Collector transistor outputs (DO1/DO2): 24 V, 50 mA, programmable. Available Available Available
✓
NOTE!
The use of the RS-485 serial interface does not allow the use of the standard RS-232 input of the MVC4 board.
They cannot be used simultaneously.
