SSW-06 - QUICK PARAMETER REFERENCE
Parameter Description Adjustable Range Factory Unit User´s Page
Setting Setting
 Local/RemoteDenition
P220
(1)
 Local/RemoteSourceSelection 0=AlwaysLocal 2=Keypad(L) - 109
1=Always Remote
  2=Keypad(L)
3=Keypad (R)
4=DI4 to DI6
  5=Serial(L)
6=Serial (R)
  7=Fieldbus(L)
8=Fieldbus (R)
  9=SoftPLC(L)
  10=SoftPLC(R)
P229
(1)
 LocalStatusCommandSelection 0=HMIKey 0=HMIKey - 110
1= Digital Inputs DIx
2=Serial
3=Fieldbus
  4=SoftPLC
P230
(1)
Remote Status Command Selection 0=HMI Key 1=Digital Inputs DIx - 110
1= Digital Inputs DIx
2=Serial
3=Fieldbus
  4=SoftPLC
P231
(1)
FWD/REV Selection 0=Inactive 0=Inactive - 110
1=By Contactor
2=JOG Only
Analog Outputs
P251 AO1 (0 to 10)V Output Function 0=Not Used 0=Not Used - 111
1= Current
(%In of the SSW)
2=Input Voltage
(%Un of the SSW)
3=Output Voltage
(%Un of the SSW)
4=Power Factor
5=Thermal Protection
6=Power (in W)
7=Power (in VA)
8=Torque
(%Tn of Motor)
9=Fieldbus
10=Serial
  11=SoftPLC
P252 AO1 Analog Output Gain 0.000 to 9.999 1.000 - 111
P253 AO2 (0 to 20)mA or (4 to 20)mA 0=Not Used 0=Not Used - 111
Output Function 1= Current
(%In of the SSW)
2=Input Voltage
(%Un of the SSW)
3=Output Voltage
(%Un of the SSW)
4=Power Factor
5=Thermal Protection
6=Power (in W)
7=Power (in VA)
