Type 01 Up to 10,000 locking operations or up to 6
years on stand-by
Type 02 Up to 10,000 locking operations or up to 6
years on stand-by
Type 04
MK
Up to 10,000 locking operations or up to 6
years on stand-by
Type 05 Up to 10,000 locking operations or up to 6
years on stand-by
Type 85 Up to 10,000 locking operations or up to 6
years on stand-by
Type 04 Up to 120,000 locking operations or up to 10
years on stand-by
Type 21 Up to 120,000 locking operations or up to 10
years on stand-by
Type 22 Up to 120,000 locking operations or up to 10
years on stand-by
Active key/
Masterkey
30,000 locking operations as a user
key or up to 4 years on standby
The locking system cylinders are suitable for installation in
T30 – T90 resistance class fire doors.
Operating temperature at
installation site
Min. 0 °C
Max. +50 °C
Supply voltage on V1 and
V2
7 V to 25 V DC
10 V to 18 V AC, 50 Hz
Maximum current con-
sumption at 12 V DC
200 mA
Low Power Source
Max. 8 A
Max. 100 VA
Switching current Max. 1.5 A @ +20 °C
Fire resistance class
Reader BOTI
Fig. 159: Drilling pattern of the
reader
Technical specifications
23.03.2020blueCompact electronic locking system186
