IP protection rating of the
reader unit
IP 54
read distances Typical: 10 mm
Dimensions reader unit
Height 100 mm
Width 42 mm
Maximum depth 16 mm
Dimensions control unit
Height 41 mm
Width 41 mm
Maximum depth 26 mm
Winkhaus access control systems are developed and pro-
duced in accordance with the applicable European stan-
dards for access control systems.
Standard Short description
EN 50133-1 Functional requirements
EN 50133-7 Planning rules
Aug. Winkhaus GmbH & Co. KG hereby declares that the
device complies with the fundamental requirements and
other relevant regulations of directive 2014/53/EU. The
extended version of the EU declaration of conformity is
available at:
https://www.winkhaus.com/de-de/eu-
konformitaetserklaerungen
Standards
Technical specifications
23.03.2020blueCompact electronic locking system188
