WPC 1000 User Manual 1125100
Initialization, Setup, and Checkout 3-31
Switch 7 – Disabling Access to Stop-time Limit and Auto Carry-up
Angle Settings
Switch 7 controls access to Stop-time Limit and Auto Carry-up Angle settings, as shown in
Table 3-11.
When set to OFF, the default setting, switch 7 enables changes to be made to the current Stop-
time Limit and Auto Carry-up Angle values stored in WPC 1000. Setting switch 7 to ON
disables this feature, preventing the operator from making changes.
Switch 8 – Top-stop Mode for F and H Errors and Auxiliary Output 1
Response to Interrupted Stroke
Switch 8 has two different functions. It controls how quickly the press top-stops when an F or
an H fault occurs, and if the Auxiliary Output on the WPC 1000 Control board has been
wired, it also specifies how that output responds to an Interrupted Stroke condition.
Selecting Top-stop Mode for F and H Errors
One switch 8 function specifies whether the press takes an additional stroke before it top-stops
when an F or an H fault occurs after 210°, as shown in Table 3-12, page 3-32.
Table 3-10. Switch 6 Settings: Enabling Cam Adjustments
Setting Access to Cam Settings
OFF Normal operation (Default). Access to cam settings
disabled.
ON Access to cam settings enabled. Cam “on” and “off”
angles can be set and adjusted.
Table 3-11. Switch 7 Settings: Disabling Access to Stop-time Limit
and Auto Carry-up Angle
Setting Access to Stop-time Limit and Auto Carry-up Angle Settings
OFF Normal operation (Default). Access to Stop-time Limit and Auto Carry-up
Angle settings enabled. Operator can change settings.
ON Access to Stop-time Limit and Auto Carry-up Angle settings disabled.
Operator cannot change settings.
PRESS MAKES ANOTHER STROKE AFTER BEING TOP-STOPPED ON F OR H ERROR
Use extreme caution if you set Switch 8 to OFF, which allows the press to complete another stroke
if an error occurs after 210°.
Failure to comply with these instructions will result in death or serious injury.
