Installing Display Board Kit with Selector Switches
1. Make sure that your display board kit contains the following components:
• Label
• PC board
• Push button
• Mute lamp
• Key switch with wiring harness assembly
• Four standoffs
• Four lock nuts.
2. Determine a convenient location to mount the display and selector switches in your
enclosure or console. Mount the display so that operators and setup personnel can easily
see the readouts and reach the switches. Make sure that all switches are no more than one
foot (300 mm) from the display.
3. Cut or punch holes in your enclosure or console for the display, selector switches, and four
#6-32 x 5/8 studs. Refer to Figure 2-29, page 2-53 for cutout dimensions for the display,
to Figure 2-28, page 2-51 for cutout dimensions for the selector switches.
4. Install the four #6-32 x 5/8 studs from inside the enclosure or console.
5. Mount the Display board on the four studs with the standoffs and lock nuts, making sure
that the LED display is at the top facing outward.
6. Orient the label correctly from outside the enclosure or console to match the cutouts, then
remove the protective paper from the label and carefully affix it.
7. Connect the display cable from J706 on the Display board to the J104 on the Control
board, referring to Installing the Display Cable, page 2-55 for instructions.
Install the panel mount display at a height convenient for all users. Experiment to determine a
good height for every user before mounting the display.
Install selector switches within one foot (300 mm) of the Display board.
