WPC 1000 User Manual 1125100
Installation 2-71
Table 2-20. WPC 1000 Display Board: Wiring Connections
Terminal Block Pin # Signal LED Grp.
& #
TB708 Mute Lamp
J707 Reset Button
Settings Key Switch
TB705 Micro-inch key switch wiring
155 Gnd
156 Top-stop in Inch (Ground to Disable) 3.2
157 WPC Input Micro-inch 3.1
TB 702
Mode Select key switch wiring
146 Gnd
147 Not used
148 Foot 1.4
149 One-hand 1.3
TB 701
Stroke Select key switch wiring
141 Gnd
142 Continuous 1.6
143 Single-stroke 1.5
144 Inch 1.8
145 Off 1.7
