1125100 WPC 1000 User Manual
2-66 Installation
When you have completed all the installation procedures in this chapter, perform the
following Installation Verification steps before setting up and initializing WPC 1000 as
instructed in Chapter 3. When you have completed initialization and set-up procedures, be
sure to perform the Final Checkout tests at the end of Chapter 3.
Checking Safeguarding Devices
Before turning on the press, check to verify the following conditions:
All fixed safeguards prevent entry of a hand or other body part into the hazardous area.
All moveable safeguards are correctly installed and wired to prevent operation of the press
when they are open and prevent entry of a hand or other body part into the hazardous area.
All interlock switches used with safeguards are designed and rated for use in safety
applications. Check with the switch manufacturer to confirm their suitability for safety use.
Interlock switches used for safeguarding are connected to control-reliable inputs.
Any light curtains are installed and working properly.
Any Two-hand controls used as safeguarding devices are mounted at least the safety
distance from the hazardous area.
Safeguards are in place to prevent entry to the hazardous area under, over or around light
curtains or other safeguarding devices.
DISPLAY DOES NOT WORK
If the WPC 1000 display does not work properly, check to make sure that the display cable is
connected correctly on both the Control and Display board ends, referring to Installing the Display
Cable, page 2-55 for help. If the display still does not work, call Wintriss Tech. Support.
DO NOT USE NON-SAFETY INTERLOCK SWITCHES IN SAFETY APPLICATIONS
Ensure that all interlock switches used on safeguards are designed and rated for safety
applications. Check with the manufacturer to verify the rating of each interlock switch.
Ensure that safety interlock switches are connected to control-reliable inputs if they are used for
safeguarding applications.
Failure to comply with these instructions will result in death or serious injury.
PREVENT INJURY DURING TESTING
Keep all personnel away from the press during testing.
Be sure there is no die or other tooling in the press during testing.
Use extreme caution when testing moveable guards. Keep hands and other body parts outside
the guarded area.
Failure to comply with these instructions will result in death or serious injury.
NOTICE
DANGER
!
DANGER
!
