Wintriss WPC 1000 User Manual

1125100 WPC 1000 User Manual
5-10 Troubleshooting
Inter-processor Failures
Problem: One of the following processor errors has occurred:
Remedy: Try pressing Reset/Select. If errors persist, contact Wintriss Tech. Support.
Input Buffer Test Failures
Problem: The following errors may occur when WPC 1000 performs input buffer tests,
which compare the input data provided by processor A with the data provided by
processor B. When the input data doesn’t match, an error is generated.
Remedy: Try pressing Reset/Select. If errors persist, contact Wintriss Tech. Support.
F30* through F37*
and
H38* and H39*
F30 Resolver angles for A and B processors disagree by more than 2°
F31 No reply to Check Start request received from second processor
F33 Incorrect reply to Mode Change message received from second processor
F34 No reply to Mode Change message received from second processor
F35 Incorrect reply to Power-up message received from second processor
F36 No reply to Reset Error message received from second processor
F37 No reply to Compare Input Buffers message received from second
processor
H38 Second processor did not receive Power-up information correctly
H39 Second processor did not receive Mode information correctly
F41* through F43*
F41 Input buffer 1 check incorrect. This test checks clutch air pressure and
motor forward inputs and user inputs 1 and 3A.
F42 Input buffer 2 check incorrect. This test checks remote reset, motor
reverse, and bar mode selector inputs.
F43 Input buffer 3 check incorrect. This test checks the DSV monitor input and
user inputs 2 and 3B.
