Wintriss WPC 1000 User Manual

WPC 1000 User Manual 1125100
Installation 2-7
Slide Adjust Considerations
If your press has a motorized slide adjustment for the ram, you must prevent slide adjustment
while the press is running. Connect spare contacts on the slide adjustment switches (i.e., Slide
Adjustment “On” or Slide Adjustment “Up”/“Down” switch) to the WPC 1000 Emergency-
stop circuit or a user interlock to stop the press as soon as the ram adjust switches on. For help
in determining how to connect this wiring, call Wintriss Tech. Support.
NON-ENCLOSURE INSTALLATION
See Installing WPC 1000 without Enclosure, page 2-48 for installation instructions if you are
installing WPC 1000 in your own enclosure or console.
Figure 2-4. WPC 1000 Mounting Dimensions
NOTICE
12.00
(304.8)
14.68
(372.8)
17.62
(447.6)
16.88
(428.8)
Note: Allow sufficient clearance
for opening door
7.27
(184.5)
14.28
(362.7)
Dimensions: inches
(mm)
WPC SETTINGSRESET/SELECT MUTE
INTERRUPTED STROKE
BRAKE WARNING
TOP STOP ANGLE
AUTO CARRYUP
ANGLE / SPM
90
° STOP TEST
STOP TIME LIMIT
MICRO-INCH
STOPPING TIME
STOPPING ANGLE
CAM 1
off
on
CAM 2
off
on
WPC 1000
Wintriss Clutch/Brake Control
MODE SELECT
1
H
A
N
D
2
H
A
N
D
F
O
O
T
MICRO INCH
O
N
O
F
F
STROKE SELECT
O
F
F
I
N
C
H
S
I
N
G
L
E
C
O
N
T
