WPC 1000 User Manual 1125100
Installation 2-17
Wiring a User-built Operator Station
If you build your own Operator Station, refer to Appendix B for applicable safety
requirements. To wire your user-built Operator Station, refer to Figure 5 at the end of the
manual. Before using your press, be sure to check the wiring carefully and run all the
applicable verification and checkout tests. After calculating the correct safety distance, you
can mount the user-built Operator Station in a permanent location.
Installing Multiple Operator Stations
If you wish to install more than one Operator Station on your WPC 1000, contact Wintriss
Tech. Support. Do not order standard Wintriss “Multiple Operator Stations” when installing
two or more Op. Stations. All Operator Stations in a multi-Op.-Station configuration must
contain a Two-hand Control module. When you install more than one Operator Station, set
option switch 5 on the WPC 1000 Control board to ON (see page 3-30). If you have any
questions about installing multiple operator stations, contact Wintriss Tech. Support.
NON-WINTRISS OPERATOR STATION MAY NOT MEET SAFETY REQUIREMENTS
• Ensure that the Operator Station is wired correctly.
• Ensure that on any non-Wintriss Operator Station the Run buttons are placed so that two hands
are required to push them at the same time and that buttons cannot be pushed simultaneously
with one hand or with one hand and one elbow.
• Ensure that on any non-Wintriss Operator Station the Run buttons comply with the requirements
specified in Table B-2, page B-2.
• Ensure that on any non-Wintriss Operator Station the Run buttons have ring guards or other
means in place to prevent unintentional operation.
• Run all necessary tests to verify that each Operator Station is wired correctly and provides
proper anti-tie-down and anti-repeat protection. Test procedures are provided at the end of this
chapter and at the end of Chapter 3.
Failure to comply with these instructions will result in death or serious injury.
HAZARDS EXPOSED BY NON-WORKING OPERATOR STATION
• Safeguard the point of operation exposed by the non-working Operator Station when using
multiple Operator Stations. The exposed area near a disabled Operator Station must be
properly guarded.
• Ensure that guarding is properly installed to prevent access to the machine over, under or
around any guarding device.
Failure to comply with these instructions will result in death or serious injury.
Use light curtains in addition to multiple Operator Stations for best personnel safeguarding
