WPC 1000 User Manual 1125100
Installation 2-19
Setting Jumpers for Shadow VII and Shadow 8 Light Curtains
When you install Shadow VII or Shadow 8 light curtains on your press, you must set jumpers
JP106 and JP107 on the WPC 1000 Control board (see Figure 2-12, page 2-21) to the
positions shown in Table 2-1. Wiring diagrams are provided in figures 8 (Shadow VII control
box), 9 (Shadow VII DIN controller), 12 (Shadow 8 optional control), and 13 (Shadow 8
wired directly to WPC 1000) at the back of the manual.
Installing Non-Shadow Light Curtains
If you plan to interface a light curtain system other than Shadow with your WPC 1000, please
call Wintriss Tech. Support for instructions.
When you call Wintriss Tech. Support, you should have the following information at hand:
• Light curtain manufacturer
• Light curtain model number
• WPC model (i.e., WPC 1000)
• WPC 1000 firmware version number (located on A or B microprocessor chip label)
• Wiring diagram from the light curtain manufacturer’s manual
If your WPC 1000 does not have the firmware that allows Foot or One-Hand control and/or
muting of a light curtain on the upstroke, you can connect the light curtain’s dry contact
outputs directly in series with WPC 1000’s E-stop string.
Table 2-1. Shadow VII and Shadow 8 Light Curtain Jumper Settings
Jumper on Control Board Settings
JP106 PNP
JP107 INT
It is your responsibility to ensure that your light curtains are control reliable and intended for use on
a mechanical power press as a primary point-of-operation guard. The manufacturer of your light
curtain should be able to provide the necessary information.
Failure to comply with these instructions could result in death or serious injury.
