WPC 1000 User Manual 1125100
Introduction 1-9
Specifications
WPC 1000 specifications are shown in Table 1-1.
Table 1-1. WPC 1000 Specifications
Control Enclosure: 12.88 x 17.62 x 7.11 in. (327.2 x 447.5 x 180.6 mm), NEMA 12,
shock-mounted.
Panel Mount: 7.50 x 10.00 in. (190.5 x 254.0 mm)
Standard items include 3-digit LED display, display indicators, Interrupted
Stroke and Brake Warning LEDs, Reset/Select button, Mute lamp, and
Settings key switch. Enclosure also provides Stroke Select key switch.
Equipment
Available from
Wintriss Controls
Resolver
0.75 in. (19 mm) keyed shaft. Rated shaft loading: 200 lb axial, 200 lb
radial.
Operator Station
NEMA 12. Includes two palm buttons, Top-stop, Emergency-stop, and Prior
Act buttons, and palm time and mute lamps. Pre-wired; unwired version
also available.
Dual Safety Valve (DSV)
Available in 0.75 in. (19 mm) or 1 in. (25 mm) Ross DM2 models.
Air Pressure Switch
12-150 PSI. Monitors clutch air supply pressure.
Wintriss AC Power
Supply (Included)
Input: 100-240 ± 10% Vac (universal switching), 50 VA, 50/60 Hz.
Output: 24 ± 1% Vdc, 200 mA maximum for customer use including
Auxiliary Output. Auxiliary Output capable of sinking 100 mA.
Power Requirements
if not Using Wintriss
AC Power Supply
24 ± 5% Vdc, 0.8 A.
Must be certified to CSA C22.2 No. 234 Standard.
Operating
Temperature
32° to 122° F (0° to 50° C).
Inputs Resolver
Overrun limit switch
One Operator Station
DSV monitor
Air pressure switch
Additional Inputs Motor
Forward and reverse contacts
Shadow Light Curtain
Checks proper functioning at every stroke initiation and stop.
Customized Status Codes
One for E-stop
One for Top-stop
One cross-checked pair for E-stop/Lockout
