1125100 WPC 1000 User Manual
5-12 Troubleshooting
Light Curtain Faults
Problem: The light curtain failed the WPC 1000 internal test. There may be a problem with
the wiring from the light curtain to WPC 1000.
Remedy: Check to make sure that light curtain wiring is correct. If you have Shadow light
curtains, refer to figures 2, 6, 7, 8, 9, 12 and 13 at the back of the manual for
correct wiring. For other light curtains, refer to the user manual for that product.
If you need additional assistance, contact Wintriss Tech. Support.
Problem: The light curtain was obstructed during the stroke.
Remedy: Remove the obstruction.
Problem: A light curtain is connected with Two-hand Only firmware installed in WPC 1000.
Remedy: Remove the Two-hand Only firmware, and install a firmware version intended for
use with a light curtain, referring to Installing Revised Firmware in WPC 1000,
page 2-46. Contact Wintriss Tech. Support for help in selecting the right firmware
for your application.
Table 5-2. Fault Codes for User Inputs
Fault
Code
User Input
(Interlock)
Stop Type Pin # Jumper
Connection
(Bypass)
51 User 1 ESTOP 45 +24 Vdc
52 User 2 TOP STOP 15 +24 Vdc
53, 17
User 3A paired
with 3B
ESTOP/
LOCKOUT
20 GROUND
User 3B paired
with 3A
6 GROUND
F60 or H60
F63
F65
