1125100 WPC 1000 User Manual
3-52 Initialization, Setup, and Checkout
14. If you want to repeat testing of the Foot Switch in Continuous mode, make sure to press
the Prior Act button before attempting to initiate another stroke.
15. Go to the next applicable test.
One-hand Control Test
This test, which should be run only if you have an optional One-hand Control, verifies that
your One-hand Control is operating properly. To perform the test, do the following, referring
to Figure 3-14, page 3-36 for LED locations on the WPC 1000 Control board:
1. Set the Stroke Select switch to “SINGLE” and the Mode Select switch to “1 HAND.”
Verify that the “Single-stroke select” and “One-hand select” LEDs on the WPC 1000
Control board are lit.
2. Make sure that option switch 3 on the WPC 1000 Control board is set to OFF, its default
setting (see Enabling Light Curtain Break Mode in a One-hand Control, page 3-28).
3. Power down, then power back up the WPC 1000, if necessary, to enable the settings
change. The WPC 1000 is now in normal One-hand Control operation, the press stroking
each time the One-hand Control switch is depressed.
4. Press the One-hand Control switch and release it immediately. The press should make a
single stroke and stop at top dead center. Verify that the “Palm switch input N/C” LED
turns off when the One-hand Control is depressed and that the “Palm switch input N/O”
LED illuminates.
INJURY DURING TESTING
• Keep all personnel away from the press during testing.
• Be sure there is no die or other tooling in the press during testing.
Failure to comply with these instructions will result in death or serious injury.
MISSING SAFEGUARDS
Install a light curtain for use with the One-hand Control option. A light curtain is required for using
the One-hand Control.
Failure to comply with these instructions will result in death or serious injury.
Depress the One-hand Control switch quickly and fully to initiate a stroke. If you depress
the One-hand Control switch slowly or partially, the press will not stroke.
