Wintriss WPC 1000 User Manual

1125100 WPC 1000 User Manual
C-2 WPC 1000 Control Board
Differences between the two boards are shown in Table C-1.
Jumper J107 is used to set the type of test (i.e., internal or external) to run on light curtain
inputs. Jumper J106 is used to set the light curtain output type (i.e., NPN or PNP). These
jumpers have been added to the new board to allow Shadow VII or Shadow 8 light curtains to
be connected directly to WPC 1000.
WPC 1000 firmware versions V 2.77 or higher are compatible with both old and new control
boards. Firmware versions lower than V 2.77 only work with the old board. If you install a
new board in WPC 1000 systems running firmware earlier than V2.77, you will get an F35
error.
Table C-1. Differences between New and Old Control Boards
Component New Board Old Board
Light Curtain Test Mode jumper
(J107)
Located beneath DSV/Lockout
Relay board (see Figure 2-12)
Not present
Light Curtain Output Type
jumper (J106)
Located beneath DSV/Lockout
Relay board (see Figure 2-12)
Not present
High/Low Speed Jumper J102 Located just below High/Low
Speed jumper J101 (see
Figure 2-12)
Located just above DSV/
Lockout Relay board (see
Figure C-1)
