1125100 WPC 1000 User Manual
3-32 Initialization, Setup, and Checkout
When switch 8 is set to OFF, its default setting, the press top-stops on the current stroke when
an F or H fault occurs before 210°, or takes an additional stroke before it top-stops if the error
occurs after 210°. When switch 8 is set to ON, the press top-stops on the current stroke if an F
or H fault occurs at any angle.
Auxiliary Output 1 Response to Interrupted Stroke
If you have wired Auxiliary Output 1 (see page 2-30), switch 8 also controls how Auxiliary 1
responds to an Interrupted Stroke condition, as shown in Table 3-13.
When switch 8 is set to OFF, its default setting, Aux. 1 turns “off” during an Interrupted
Stroke and whenever a fault occurs, an E-stop string opens, or a light curtain is broken with
the press running. When switch 8 is set to ON, the Auxiliary Output stays “on” during an
Interrupted Stroke when no fault condition or E-stop occurs but turns “off” whenever there is
a fault, an open E-stop string, or a light curtain interruption.
* An Interrupted Stroke cannot occur in Inch mode.
Table 3-12. Switch 8 Settings: Top-stop Mode for F and H Errors
Setting Top-stop Behavior for F and H Errors
OFF Normal operation (Default). Press top-stops on
current stroke when F or H fault occurs before 210°,
on next stroke if error occurs after 210°.
ON Press top-stops on current stroke at whatever angle
an F or H error occurs.
NON-SAFETY OUTPUT USED FOR SAFETY FUNCTIONS
Use Auxiliary Output 1 for a non-safety function only, such as convenience in automation. It
cannot protect personnel from a moving hazard.
Failure to comply with these instructions will result in death or serious injury.
Table 3-13. Switch 8 Setting: Auxiliary Output 1 Response to Interrupted Stroke
Settings Auxiliary Output 1 State Change
OFF Normal operation (Default). Aux. 1 turns “off” when one of the
following occurs:
an Interrupted Stroke* condition
a fault condition (error code displays)
an open E-stop string
a light curtain interruption while press is running
ON Aux. 1 stays “on” during Interrupted Stroke if no fault condition
or E-stop occurs, turns “off” when one of the following occurs:
a fault condition (error code displays)
an open E-stop string
a light curtain interruption while press is running
