2-70 Installation
Table 2-17. WPC 1000 Control Board: Resolver (TB103) Wiring Connections
CW (clockwise) rotation shown, viewing from shaft end.
For CCW, reverse black and yellow wires.
Pin # Signal
55 Shield
54 S1 Sine (Black)
53 S2 Cosine (Green)
52 R1 drive (Red)
51 S3 ground (Yellow)
50 R2 ground (Orange)
49 S4 ground (Brown)
Table 2-18. WPC 1000 Control Board: DSV/Lockout Relay Board Wiring Connections
Terminal Block Pin # Signal
TB303 64 DSV A Relay
63 DSV A Relay
TB302 62 DSV B Relay
61 DSV B Relay
TB301 60 Lockout Relay OUT
59 Lockout Relay OUT
58 Lockout Relay IN
Table 2-19. WPC 1000 Control Board: Power (J103) Wiring Connections
Terminal Block Pin # Signal
J103
56 Com
57 +24 Vdc
