WPC 1000 User Manual 1125100
Installation 2-49
The power supply on the mounting plate is pre-wired to the power terminal, J103, on the
Control board and to the input power terminal block on the plate. To connect AC wiring to
the input power terminal block, follow the instructions in Connecting AC Wiring, page 2-8.
Installing the Panel-mount Display
Mounting the Display
To install the panel-mount display in your enclosure or console, do the following, referring to
Figure 2-27, page 2-50 for mounting and cutout dimensions:
1. Determine a convenient location to mount the display panel and selector switches in your
enclosure or console. Mount the display so that operators and setup personnel can easily
see the readouts and reach the switches. Make sure that all switches are no more than one
foot (300 mm) from the display.
2. Cut out a hole in your enclosure or console, and drill and tap twelve holes for #10-32
screws, referring to Figure 2-27.
3. Prop the display panel near the location where you plan to mount it. You can do this by
connecting ty wraps from two of the left holes on the panel to the corresponding holes on
the enclosure or console, creating hinges. Allow 9 in. of service loop when performing the
wiring connections, and make sure all cables will reach the connectors.
Install the panel mount display at a height convenient for all users. Experiment to determine a
good height for every user before mounting the display.
