1125100 WPC 1000 User Manual
2-2 Installation
ELECTRIC SHOCK OR HAZARDOUS ENERGY
• Disconnect main power before installation.
• Remove all power to the press, press control, and other equipment used with the press.
• Remove all fuses and “tag out” per OSHA 1910.147 Control of Hazardous Energy (Lockout/
Tagout).
• Ensure that installation is performed by qualified personnel.
• Complete all installation procedures before connecting to the AC power source.
Failure to comply with these instructions will result in death or serious injury.
When you have completed installation procedures, perform the tests in the Installation Verification
section, page 2-65 to ensure that WPC 1000 is installed correctly and working properly before
proceeding to Chapter 3.
ALL SIGNAL GROUNDS MUST BE CONNECTED THROUGH THE CONTROL BOARD
Connect all signal grounds through pins on the WPC 1000 Control board.
READ INSTALLATION INSTRUCTIONS BEFORE STARTING INSTALLATION
If you install WPC 1000 yourself, read this installation chapter carefully and plan how you are
going to proceed before you start drilling holes, running conduit, or cutting wires. Make sure you
are familiar with the WPC 1000 display (see page 1-5). If you encounter problems during
installation, contact Wintriss Tech. Support.
PRESS MUST BE AT TDC
Before starting installation, make sure that the die has been removed from the press and the press
ram has been moved to top dead center (TDC). The press must be at TDC when you make final
adjustments for the resolver. The TDC setting should be 0° ±2°. Use a dial indicator on the face
of the ram if necessary, to ensure that the ram is positioned correctly.
